Glue Points: if your component needs to be glued to board, you show where to apply glue
Assembly: Layer which is shown in Assembly documentation - usually component outline + designator (used mostly by assembly house to localize your components on PCB)Ĭoating: If you need to cover some areas of PCB by additional layer of somethingĬomponent Center: I guess, this shows footprint 0,0 positionĬomponent Outline: Usually the white color on PCB around componentĬourtyard: area used by component (for example to help you to be sure, that there will be no collision between two components placed too close to each other)ĭesignator: Component designator e.g.
